Xdl10

Basic Info.

Model NO.	XDL10-EPB6P/TA
Principle	Capacitive
Application	Electronics, Industrial
Type	Normal Open
Number of Switch	Single Control Switch
Structure	Power Built-in Type
Usage	Control Button, Start Button, Control Switch
Kind	Single-pole on-off Switch
Contact Type	Type a Contact
Detection Method	Retro-reflective Mode
Brand	Xindali
Certification	ISO9001, CE, TUV RoHS
Voltage	AC 110-250V
Max. Voltage	500V
Transport Package	Box
Trademark	XINDALI
Origin	China
HS Code	8536909000
Production Capacity	100000PCS/Month

Packaging & Delivery

Package Size 10.00cm * 10.00cm * 10.00cm Package Gross Weight 0.100kg

Product Description

Product DescriptionXDL10 Series Control Switch is aesthetic design, durable quality, lightweight holding, reasonable structurewith various functions; UP and DOWN direction controlling under protection of circuit interlocking and ensure the power circuit issafe and reliable; Assembled with cable gland and waterproof sealing to reach good waterproof performance (up to IP65); Thisproduct is suitable for outdoor, dusty and other harsh environment.

Product parameters
Standard usage status	Operating ambient temperature		-20~+55ºC
	Ambient humidity		45~85%
contact resistance	≤50mΩ
insulation resistance	≥100mΩ
Pollution grade	3
Withstand voltage	AC2.5kV/min
Mechanical life	>1 million times
Electrical life	>100000 times
Cable length	2m(it can be customized )
Wire gauge	1mm(18AWG)
Protection degree	IP65
Rated insulation voltage	AC600V
Rated thermal current	10A
Rated use voltage	120V		240V		400V
Rated usage current	AC	AC-15	6A	3A	1.5A
	DC	DC-13	0.55A	0.27A	0.15A

Product Show

Use environment

Our CompanyCertificationsOur AgentWhy Choose UsWhat is your MOQ? MOV?We don't have MOQ for the standard items. And the MOV for the terms of FOB is 5000USD.What are your terms of payment?We accept T/T, L/C payment.Can I pay by PAYPAL?Yes, our Paypal account How long is the delivery date?The standard lead time 2 weeks.What certifications does this product have?We have CE, Rohs, UL and TUV approvals.Are you a manufacturer? Where is the factory?Yes, we are manufacturer, our factory located in Wenzhou.Can you do OEM?Yes, we can offer customized service under OEM.Why your price is higher than others?If we are talking about the same qualitiy level, our price will be competitve.How long is the guarantee of your products?We have 5 years guarantee.Do you have water-proof items?Yes, our XDL22 and XDL722 series are IP65.Can you provide me with samples for free?Yes, the samples can be offered as free of charge.Can you provide certificate of origin?Yes, we can.Can you customize the product for me?Yes, we have our own R&D team and tool centre to make customized products.Does Xindali have agent?Yes, we have agent of Xindali brand in Italy, Sweden, Norway, Finland, Russia, Greece, Spain and UK.What support can I get if I become your agent?If you will be our agent, you will get the following VIP service,* Professinal Technical support from Xindali Team* Special Price support* Lead Time support* Samples boards support* Payment support
